Call For Pricing

New 2025 Ford F-600 Regular Cab 4x4 Bucket Truck

Stock #1SDA04387
Dealer Video

Vehicle Notes

2025 Ford F-600XL regular cab conventional truck, GVWR 22,000 lbs., 6.7L Power Stroke Diesel engine, 10-Sp automatic transmission, steel wheels, R19.5…
Read More…
2025 Ford F-600XL regular cab conventional truck, GVWR 22,000 lbs., 6.7L Power Stroke Diesel engine, 10-Sp automatic transmission, steel wheels, R19.5 tires, spring suspension, hydraulic brakes, 3-passenger grey cloth interior, AM/FM/BT radio, A/C, power windows and locks, ..., BrandFX 102T line body with Telescopic articulating material handling bucket truck Top mounted jib and winch Max working height range: 43' - 59' Max side reach range: 27' 6 - 31' 6 Insulated or non-insulated versions Single or double person baskets 180-degree basket rotator 22 basket elevator Lift up to 1000# The DPM2 material handling articulating telescopic aerial lift was designed to make trouble truck operation simple enough to be a one-person job. Conveniently located controls make positioning of personnel and materials easy, efficient, and exact. The operator can utilize one hand to maneuver the materials and the other to position the aerial lift. This Series 2 model features our new top mounted jib that allows the operator to rotate the jib to work on either side of the rotating basket and winch and as well as a hydraulically activated basket elevator allows the operator to raise the basket 22 without repositioning the booms or the jib. The -35-boom angle allows access to the basket right from ground level and you can access all the storage compartments right from the basket. Available with a single- or double-person basket in insulated or non-insulated formats. Height to bottom of platform*: 54 Working height*: 59 Side reach: 31.6 Stowed travel height: 118 Platform capacity (MH): 400# Platform capacity using jib (DU): 400# Platform capacity not using jib (DU): 550# Approximate weight: 4400# Articulating arm travel: 0 to 75 Main Boom Travel: -30 to 75 Extension travel: 120 STANDARD FEATURES Proportional controls Lower override controls Engine start/stop from basket. Basket access from ground Compensated upper boom Insulated models available in category C, D and E Hydraulic basket leveling Continuous rotation Joystick and lockout controls 180 basket rotator Up to 1000# top mounted jib and winch 400# basket capacity.
Read Less

Chassis Details

Stock Number
1SDA04387
Stock Type
New
Year
2025
Make
Ford
Model
F-600
Class
6
Drivetrain
4x4
Cab Type
Regular
Vehicle Trim
Dur-A-Lift DPM2-52DU 59' Insulated Bucket Truck
Vehicle VIN
1FDFF6LT1SDA04387
Interior Color
Medium Dark Slate
Exterior Color Description
Oxford White
Engine Cylinder Count
8
Engine
6.7L 4v OHV Power Stroke V8 Turbo Diesel B20 Engine
Transmission Type
Automatic
Rear Wheels
Dual
Fuel Type
Diesel
Engine Make
Ford
Engine Size (L)
6.7
Brake Type
Hydraulic

Vehicle Options

  • Fixed Antenna
  • Radio w/Seek-Scan, Clock and Speed Compensated Volume Control
  • Radio: AM/FM Stereo w/MP3 Player -inc: 4 speakers
  • 2 LCD Monitors In The Front
  • SYNC 4 Communication & Entertainment System -inc: enhanced voice recognition, 911 Assist, 8 LCD center stack screen, AppLink and 1 smart-charging USB port
  • Cab Clearance Lights
  • Fixed Rear Window
  • Black Power Heated Side Mirrors w/Convex Spotter, Manual Folding and Turn Signal Indicator
  • Perimeter/Approach Lights
  • Black Fender Flares
  • Autolamp Auto On/Off Reflector Halogen Daytime Running Lights Preference Setting Headlamps w/Delay-Off
  • Black Front Bumper w/Black Rub Strip/Fascia Accent and 2 Tow Hooks
  • Wheels: 19.5 x 6.75 Argent Painted Steel
  • Manual Extendable Trailer Style Mirrors
  • Aluminum Panels
  • Light Tinted Glass
  • Black Grille
  • Tires: 245/70Rx19.5G BSW A/P -inc: Spare may not be the same as road tire
  • Variable Intermittent Wipers
  • Front Splash Guards
  • Black Door Handles
  • Black Side Windows Trim and Black Front Windshield Trim
  • Power 1st Row Windows w/Driver And Passenger 1-Touch Up/Down
  • Driver Information Center
  • Manual Tilt/Telescoping Steering Column
  • Securilock Anti-Theft Ignition (pats) Immobilizer
  • 2 12V DC Power Outlets
  • 4-Way Driver Seat -inc: Manual Recline and Fore/Aft Movement
  • Compass
  • Seats w/Vinyl Back Material
  • Full Overhead Console w/Storage and 2 12V DC Power Outlets
  • Smart Device Remote Engine Start
  • Full Cloth Headliner
  • Manual Air Conditioning
  • Illuminated Locking Glove Box
  • Trip Computer
  • Interior Trim -inc: Chrome Interior Accents
  • Air Filtration
  • Digital/Analog Appearance
  • Perimeter Alarm
  • Instrument Panel Covered Bin and Dashboard Storage
  • Remote Keyless Entry w/Integrated Key Transmitter, Illuminated Entry and Panic Button
  • 4-Way Passenger Seat -inc: Manual Recline and Fore/Aft Movement
  • FordPass Connect 5G Mobile Hotspot Internet Access
  • Gauges -inc: Speedometer, Odometer, Oil Pressure, Engine Coolant Temp, Tachometer, Transmission Fluid Temp, Engine Hour Meter, Trip Odometer and Trip Computer
  • Front Map Lights
  • Power Door Locks w/Autolock Feature
  • Cruise Control w/Steering Wheel Controls
  • Fade-To-Off Interior Lighting
  • Delayed Accessory Power
  • Manual Adjustable Front Head Restraints
  • Passenger Visor Vanity Mirror
  • Day-Night Rearview Mirror
  • Urethane Gear Shifter Material
  • Outside Temp Gauge
  • Full Vinyl/Rubber Floor Covering
  • HD Vinyl 40/20/40 Split Bench Seat -inc: center armrest, cupholder, storage, 2-way adjustable driver/passenger headrests and driver's side manual lumbar
  • Single Stainless Steel Exhaust
  • Firm Suspension
  • 190 Amp Alternator
  • Engine: 7.3L 2V DEVCT NA PFI V8 Gas
  • HD Gas-Pressurized Shock Absorbers
  • Front Suspension w/Coil Springs
  • 14880# Maximum Payload
  • 4-Wheel Disc Brakes w/4-Wheel ABS, Front And Rear Vented Discs, Brake Assist and Hill Hold Control
  • Transmission: TorqShift 10-Speed Automatic -inc: SelectShift, selectable drive modes: normal, tow/haul, eco, slippery roads and off-road and transmission power take-off provision
  • Electronic Transfer Case
  • GVWR: 22,000 lbs Payload Package
  • Part-Time Four-Wheel Drive
  • 50-State Emissions System
  • Upfitter Switches
  • Front And Rear Anti-Roll Bars
  • Limited Slip w/4.88 Axle Ratio
  • Auto Locking Hubs
  • Trailer Wiring Harness
  • Towing Equipment -inc: Trailer Sway Control
  • Hydraulic Power-Assist Steering
  • Transmission w/Oil Cooler
  • Dual Rear Wheels
  • Solid Axle Rear Suspension w/Leaf Springs
  • 40 Gal. Fuel Tank
  • 68-Amp/Hr 750CCA Maintenance-Free Battery w/Run Down Protection
  • Driveline Traction Control
  • Tire Specific Low Tire Pressure Warning
  • AdvanceTrac w/Roll Stability Control Electronic Stability Control (ESC) And Roll Stability Control (RSC)
  • Dual Stage Driver And Passenger Seat-Mounted Side Airbags
  • Outboard Front Lap And Shoulder Safety Belts -inc: Height Adjusters
  • Lane Departure Warning
  • Pre-Collision Assist with Automatic Emergency Braking (AEB)
  • Collision Mitigation-Front
  • Safety Canopy System Curtain 1st Row Airbags
  • Dual Stage Driver And Passenger Front Airbags w/Passenger Off Switch
  • Side Impact Beams
  • View All

Body Details

Body Type
Bucket Truck
Call For Pricing

Pricing Details

Vehicle available NOW in Homestead, FL.

Contact Truck Max Homestead for more info.
